A matrix of 16 values for 3d calculations in homogeneous coordinates. More...

Collaboration diagram for a3d::Matrix4< T, M >:

Classes
struct	Interpolator
	Struct performing interpolation between two matrices. More...

Public Member Functions
	Matrix4 ()
	Creates an uninitialized matrix. More...

	Matrix4 (int i)
	Creates a unit matrix. More...

	Matrix4 (const Matrix4< T > &x)
	Copy constructor. More...

template<class T2 >
	Matrix4 (const Matrix4< T2 > &x)
	Copy constructor. More...

template<class T2 , class M2 >
	Matrix4 (const Vector4< T2, M2 > &v0, const Vector4< T2, M2 > &v1, const Vector4< T2, M2 > &v2, const Vector4< T2, M2 > &v3=Vector4< T2, M2 >(0, 0, 0, 1))
	Creates matrix from three or four column vectors. More...

template<class T2 , class M2 >
	Matrix4 (const Vector3< T2, M2 > &v0, const Vector3< T2, M2 > &v1, const Vector3< T2, M2 > &v2, const Vector3< T2, M2 > &v3=Vector3< T2, M2 >(0, 0, 0))
	Creates matrix from three or four column vectors. More...

template<class S >
	Matrix4 (S m00, S m01, S m02, S m03, S m10, S m11, S m12, S m13, S m20, S m21, S m22, S m23, S m30, S m31, S m32, S m33)
	Creates matrix from elements specified in row-major order. More...

template<class T2 , class M2 >
	Matrix4 (const Matrix3< T2, M2 > &x)
	Casting from Matrix3. More...

template<class T2 , class M2 >
	Matrix4 (const Quaternion< T2, M2 > &q)
	Casting from Quaternion. More...

void	loadIdentity ()
	Make this matrix identity, i.e. More...

Matrix3< T, M >	getScaleRotation () const

Vector3< T, M >	getTranslation () const

bool	separate (Vector3< T, M > &scale, Matrix3< T, M > &rotation, Vector3< T, M > &translation) const
	Separates the transform represented by this matrix into scale, translation and rotation. More...

Matrix4< T, M >	transpose () const
	Creates a transposed version of the matrix. More...

T	determinant () const
	Calculates the determinant. More...

Matrix4< T, M >	comatrix () const
	Calculates the comatrix. More...

Matrix4< T, M >	inverse () const
	Returns the inverse of the matrix. More...

Matrix4< T, M >	affineInverse () const
	Returns the inverse of the affine matrix. More...

Matrix4< T, M > &	operator= (const Matrix4< T, M > &o)
	Copy operator. More...

template<class T2 , class M2 >
Matrix4< T, M > &	operator= (const Matrix4< T2, M2 > &o)
	Copy operator. More...

	operator const T * () const
	Casts this matrix to an array representation. More...

	operator T * ()
	Casts this matrix to an array representation. More...

const T &	operator() (int i, int j) const
	Index access (row,col) More...

const T &	operator[] (int i) const
	Index operator. More...

T &	operator() (int i, int j)
	Index access (row,col) More...

T &	operator[] (int i)
	Index operator. More...

Static Public Member Functions
template<class T2 , class M2 >
static Matrix4< T, M >	fromTranslation (const Vector3< T2, M2 > &v)
	Creates a translating matrix. More...

template<class S >
static Matrix4< T, M >	fromArrayRM (const S *ma)
	Create a matrix from a array representation of an array in row-major mode. More...

template<class S >
static Matrix4< T, M >	fromArrayCM (const S *ma)
	Create a matrix from a array representation of an array in column-major mode. More...

Public Attributes
T	m [16]
	Matrix cell data. More...

Detailed Description

template<class T, class M = Math<T>>
struct a3d::Matrix4< T, M >

A matrix of 16 values for 3d calculations in homogeneous coordinates.

Observe that the data is stored in column-major mode for easy interfacing with OpenGL. The interfaces are specified in row-major mode (for example the constructor and print operator).

Constructor & Destructor Documentation

template<class T, class M = Math<T>>

a3d::Matrix4< T, M >::Matrix4 ( )

inline

Creates an uninitialized matrix.

template<class T, class M = Math<T>>

a3d::Matrix4< T, M >::Matrix4 ( int i )

inlineexplicit

Creates a unit matrix.

References a3d::Matrix4< T, M >::loadIdentity().

Here is the call graph for this function:

template<class T, class M = Math<T>>

a3d::Matrix4< T, M >::Matrix4 ( const Matrix4< T > & x )

inline

Copy constructor.

References a3d::Matrix4< T, M >::m.

template<class T, class M = Math<T>>

template<class T2 >

a3d::Matrix4< T, M >::Matrix4 ( const Matrix4< T2 > & x )

inline

Copy constructor.

References a3d::Matrix4< T, M >::m.

template<class T, class M = Math<T>>

template<class T2 , class M2 >

a3d::Matrix4< T, M >::Matrix4	(	const Vector4< T2, M2 > &	v0,
		const Vector4< T2, M2 > &	v1,
		const Vector4< T2, M2 > &	v2,
		const Vector4< T2, M2 > &	v3 = `Vector4<T2,M2>(0,0,0,1)`
	)

inline

Creates matrix from three or four column vectors.

References a3d::Matrix4< T, M >::m.

template<class T, class M = Math<T>>

template<class T2 , class M2 >

a3d::Matrix4< T, M >::Matrix4	(	const Vector3< T2, M2 > &	v0,
		const Vector3< T2, M2 > &	v1,
		const Vector3< T2, M2 > &	v2,
		const Vector3< T2, M2 > &	v3 = `Vector3<T2,M2>(0,0,0)`
	)

inline

Creates matrix from three or four column vectors.

References a3d::Matrix4< T, M >::m.

template<class T, class M = Math<T>>

template<class S >

a3d::Matrix4< T, M >::Matrix4	(	S	m00,
		S	m01,
		S	m02,
		S	m03,
		S	m10,
		S	m11,
		S	m12,
		S	m13,
		S	m20,
		S	m21,
		S	m22,
		S	m23,
		S	m30,
		S	m31,
		S	m32,
		S	m33
	)

inline

Creates matrix from elements specified in row-major order.

References a3d::Matrix4< T, M >::m.

template<class T, class M = Math<T>>

template<class T2 , class M2 >

a3d::Matrix4< T, M >::Matrix4 ( const Matrix3< T2, M2 > & x )

inlineexplicit

Casting from Matrix3.

References a3d::Matrix3< T, M >::m, and a3d::Matrix4< T, M >::m.

template<class T, class M = Math<T>>

template<class T2 , class M2 >

a3d::Matrix4< T, M >::Matrix4 ( const Quaternion< T2, M2 > & q )

inlineexplicit

Casting from Quaternion.

References a3d::Matrix4< T, M >::m, a3d::Quaternion< T, M >::s, and a3d::Quaternion< T, M >::v.

Member Function Documentation

template<class T, class M = Math<T>>

Matrix4<T,M> a3d::Matrix4< T, M >::affineInverse ( ) const

inline

Returns the inverse of the affine matrix.

This function will produce an unknown result if applied to a matrix that does not represent an affine transform.

References a3d::Matrix4< T, M >::fromTranslation(), a3d::Matrix4< T, M >::getScaleRotation(), and a3d::Matrix4< T, M >::getTranslation().

Here is the call graph for this function:

template<class T, class M = Math<T>>

Matrix4<T,M> a3d::Matrix4< T, M >::comatrix ( ) const

inline

Calculates the comatrix.

References A3D_WARNING_EXPENSIVE, and a3d::Matrix4< T, M >::m.

Referenced by a3d::Matrix4< T, M >::inverse().

template<class T, class M = Math<T>>

T a3d::Matrix4< T, M >::determinant ( ) const

inline

Calculates the determinant.

References A3D_WARNING_EXPENSIVE, and a3d::Matrix4< T, M >::m.

Referenced by a3d::Matrix4< T, M >::inverse().

template<class T, class M = Math<T>>

template<class S >

static Matrix4<T,M> a3d::Matrix4< T, M >::fromArrayCM ( const S * ma )

inlinestatic

Create a matrix from a array representation of an array in column-major mode.

[ (00), (10), (20), (30), (01), ... ]

template<class T, class M = Math<T>>

template<class S >

static Matrix4<T,M> a3d::Matrix4< T, M >::fromArrayRM ( const S * ma )

inlinestatic

Create a matrix from a array representation of an array in row-major mode.

[ (00), (01), (02), (03), (10), ... ]

template<class T, class M = Math<T>>

template<class T2 , class M2 >

static Matrix4<T,M> a3d::Matrix4< T, M >::fromTranslation ( const Vector3< T2, M2 > & v )

inlinestatic

Creates a translating matrix.

Referenced by a3d::Matrix4< T, M >::affineInverse().

template<class T, class M = Math<T>>

Matrix3<T,M> a3d::Matrix4< T, M >::getScaleRotation ( ) const

inline

References a3d::Matrix4< T, M >::m.

Referenced by a3d::Matrix4< T, M >::affineInverse().

template<class T, class M = Math<T>>

Vector3<T,M> a3d::Matrix4< T, M >::getTranslation ( ) const

inline

References a3d::Matrix4< T, M >::m.

Referenced by a3d::Matrix4< T, M >::affineInverse().

template<class T, class M = Math<T>>

Matrix4<T,M> a3d::Matrix4< T, M >::inverse ( ) const

inline

Returns the inverse of the matrix.

This function is not optimized and is therefore extremely inefficient.

References A3D_WARNING_EXPENSIVE, a3d::Matrix4< T, M >::comatrix(), and a3d::Matrix4< T, M >::determinant().

Referenced by a3d::Vector3< T, M >::fromScreenPosition().

Here is the call graph for this function:

template<class T, class M = Math<T>>

void a3d::Matrix4< T, M >::loadIdentity ( )

inline

Make this matrix identity, i.e.

ones in diagonal.

References a3d::Matrix4< T, M >::m.

Referenced by a3d::Matrix4< T, M >::Matrix4().

template<class T, class M = Math<T>>

a3d::Matrix4< T, M >::operator const T * ( ) const

inline

Casts this matrix to an array representation.

This makes it possible to provide for example a float matrix as an array argument in for example OpenGL.

References a3d::Matrix4< T, M >::m.

template<class T, class M = Math<T>>

a3d::Matrix4< T, M >::operator T * ( )

inline

Casts this matrix to an array representation.

This makes it possible to provide for example a float matrix as an array argument in for example OpenGL. Anything written in the returned array will end up in the matrix.

References a3d::Matrix4< T, M >::m.
