This abstract interface is inherited by all nodes that could be used as vertex attributes in a glsl shader. More...
#include <H3D/GLVertexAttributeObject.h>
Public Member Functions | |
| GLVertexAttributeObject (VERTEXATTRIBUTE::VERTEXATTRIBUTETYPE type) | |
| Constructor. | |
| virtual | ~GLVertexAttributeObject () |
| Destructor. | |
| virtual void | setAttributeData ()=0 |
| pure virtual function has to be implemented by inherited class to specify necessay data and format for this vertex attrib | |
| virtual void | renderVBO ()=0 |
| pure virtual function has to be implemented by inherited class to specify the actual render function | |
| virtual void | disableVBO ()=0 |
| pure virtual function has to be implemented by inherited class to specify the actual render disable function | |
| virtual bool | preRenderCheckFail () |
| pre-render check to dertermine if need to render this vertex attribute | |
| void | renderVertexBufferObject () |
| Perform the OpenGL commands to render all vertices as a vertex buffer object. | |
| void | disableVertexBufferObject () |
| Disable the vertex buffer object enabled in renderVertexBufferObject(). | |
| virtual void | updateVertexBufferObject () |
| Perform the OpenGL commands to update vertex attribute data/format. | |
Public Attributes | |
| H3DUniquePtr< SFBool > | isDynamic |
| Option to indicate whether this vertex attribute is dynamic or not Access type: inputOutput Default value: false. | |
Protected Attributes | |
| H3DUniquePtr< Field > | vboFieldsUpToDate |
| Internal field used to know if vertex buffer object can be created. More... | |
Detailed Description
This abstract interface is inherited by all nodes that could be used as vertex attributes in a glsl shader.
Example of such nodes are Color, Coordinate and Normal nodes.
Member Data Documentation
◆ vboFieldsUpToDate
|
protected |
Internal field used to know if vertex buffer object can be created.
C++ only field
Referenced by H3D::Color::Color(), H3D::ColorRGBA::ColorRGBA(), H3D::Coordinate::Coordinate(), H3D::CoordinateDouble::CoordinateDouble(), H3D::FloatVertexAttribute::FloatVertexAttribute(), GLVertexAttributeObject(), H3D::Matrix3VertexAttribute::Matrix3VertexAttribute(), H3D::Matrix4VertexAttribute::Matrix4VertexAttribute(), H3D::Normal::Normal(), H3D::TextureCoordinate::TextureCoordinate(), H3D::TextureCoordinate3D::TextureCoordinate3D(), H3D::TextureCoordinate4D::TextureCoordinate4D(), and updateVertexBufferObject().
The documentation for this class was generated from the following files:
