DeviceLog records haptic device data to a binary data file. More...
#include <H3D/DeviceLog.h>
Public Member Functions | |
| DeviceLog (Inst< SFNode > _metadata=0, Inst< MFString > _url=0, Inst< SFInt32 > _frequency=0, Inst< MFInt32 > _deviceIndex=0, Inst< SFBool > _logBinary=0, Inst< MFString > _logData=0, Inst< OnClose > _close=0) | |
| Constructor. | |
| virtual | ~DeviceLog () |
| Destructor. More... | |
| virtual void | traverseSG (TraverseInfo &ti) |
| Adds the effect to be rendered in the haptics loop. More... | |
 Public Member Functions inherited from H3D::H3DForceEffect | |
| H3DForceEffect (Inst< SFNode > _metadata=0, Inst< MFInt32 > _deviceIndex=0) | |
| Constructor. | |
| Public Member Functions inherited from H3D::X3DChildNode | |
| X3DChildNode (Inst< SFNode > _metadata=0) | |
| Constructor. | |
| Public Member Functions inherited from H3D::X3DNode | |
| X3DNode (Inst< SFNode > _metadata=0) | |
| Constructor. | |
| X3DMetadataObject * | getMetadataByName (const string &_name) |
| Given a name, the first X3DMetadataObject in the metadata field that matches that name is returned. More... | |
| Public Member Functions inherited from H3D::Node | |
| Node () | |
| Constructor. | |
| virtual Node * | clone (bool deepCopy=true, DeepCopyMap *deepCopyMap=NULL) |
| Returns a new instance of this node type with the same state as this one. More... | |
| virtual | ~Node () |
| Destructor. | |
| X3DPrototypeInstance * | getProtoInstanceParent () |
| If this node is the root node in the proto body of a X3DPrototypeInstance then this will return that node. More... | |
| void | setProtoInstanceParent (X3DPrototypeInstance *p) |
| Set the X3DPrototypeInstance this node is the the root node if applicaple. | |
| virtual void | render () |
| the render() function is used for the depth-first rendering traversal of the scene-graph. More... | |
| virtual bool | lineIntersect (const Vec3f &from, const Vec3f &to, LineIntersectResult &result) |
| Detect intersection between a line segment and the Node. More... | |
| virtual void | closestPoint (const Vec3f &p, NodeIntersectResult &result) |
| Find closest point on Node to p. More... | |
| virtual bool | movingSphereIntersect (H3DFloat radius, const Vec3f &from, const Vec3f &to, NodeIntersectResult &result) |
| Detect collision between a moving sphere and the Node. More... | |
| virtual string | defaultXMLContainerField () |
| Returns the default xml containerField attribute value. More... | |
| virtual Field * | getField (const string &_name) const |
| return a pointer to the field specified by name within this instance | |
| int | addDestructCallback (void(*func)(Node *, void *), void *args) |
| Add a callback function to be run on destruction of node. More... | |
| int | removeDestructCallback (void(*func)(Node *, void *), void *args) |
| Add a callback function to be run on destruction of node. More... | |
| Public Member Functions inherited from H3D::X3DUrlObject | |
| X3DUrlObject (Inst< MFString > _url=0) | |
| Constructor. | |
| virtual LoadStatus | loadStatus () |
| The loadStatus function returns the status of the loading of the current urls in order to be used with the LoadSensor node. | |
| virtual H3DFloat | loadProgress () |
| The loadProgress() functions returns a value between 0 and 1 indicating how much of the current url has been loaded. More... | |
| void | setURLUsed (const string &_url_used) |
| Set the url that is currently loaded. | |
| const string & | getURLUsed () |
| Get the url that is currently loaded. | |
| void | setURLBase (const string &_url_base) |
| Set the url base address. | |
| const string & | getURLBase () |
| Get the current url base address. | |
| string | resolveURLAsFile (const string &url, bool *is_tmp_file=NULL) |
| Get the url as a local file. | |
| string | resolveURLAsString (const string &url) |
| Get the content of the URL as a string. | |
| bool | removeTmpFile (const string &file) |
| Remove a tmpfile with the given name. More... | |
Public Attributes | |
| H3DUniquePtr< SFInt32 > | frequency |
| The log frequency. More... | |
| H3DUniquePtr< SFBool > | logBinary |
| If true the logging will be done to a binary file. More... | |
| H3DUniquePtr< MFString > | logData |
| Specifies what to log. More... | |
| H3DUniquePtr< OnClose > | close |
| If set to true the log file is closed immediately. More... | |
| Public Attributes inherited from H3D::H3DForceEffect | |
| H3DUniquePtr< MFInt32 > | deviceIndex |
| A list of indices that tells which haptics devices to render the force on. More... | |
| Public Attributes inherited from H3D::X3DNode | |
| H3DUniquePtr< SFNode > | metadata |
| Meta data about the node. More... | |
| Public Attributes inherited from H3D::X3DUrlObject | |
| H3DUniquePtr< MFString > | url |
| The urls in decreasing order of preference. | |
Static Public Attributes | |
| static H3DNodeDatabase | database |
| The H3DNodeDatabase for this node. | |
| Static Public Attributes inherited from H3D::H3DForceEffect | |
| static H3DNodeDatabase | database |
| The H3DNodeDatabase for this node. | |
| Static Public Attributes inherited from H3D::X3DNode | |
| static H3DNodeDatabase | database |
| The H3DNodeDatabase for this node. | |
Protected Member Functions | |
| void | createLogForceEffect (int index) |
| Internal function used to create a log force effect for the haptics device of the given index. | |
| virtual HAPI::DeviceLog * | createHAPIDeviceLog (const std::string &_url) |
| Create a new instance of the HAPI DeviceLog class used to implement the recording. | |
| HAPI::DeviceLog::LogTypeVector | getLogTypes () |
| Returns a list of parameters to be logged by the HAPI DeviceLog class. | |
| Protected Member Functions inherited from H3D::Node | |
| void | cloneFieldValue (Field &_from, Field &_to, bool deepCopy, DeepCopyMap &deepCopyMap) |
| A helper function for the clone() method. More... | |
| Protected Member Functions inherited from H3D::X3DUrlObject | |
| string | resolveURL (const string &_url, bool return_contents, bool *is_tmp_file=NULL) |
| Helper function for resolveURLAs*() functions. | |
| void | addInlinePrefix (const string &s) |
| Add a inline prefix that this node supports. | |
| int | getInlinedContentOffset (const std::string &url) |
| If the URL contains any inline prefix, return the index of the start of the inlined content. More... | |
Protected Attributes | |
| AutoRefVector< HAPI::DeviceLog > | log_force_effect |
| Internal haptic force effect instance. | |
| Protected Attributes inherited from H3D::X3DUrlObject | |
| string | url_used |
| If loadStatus() returns LOADED this string should contain the url that is loaded. More... | |
| string | url_base |
| The base URL for urls in this url object. More... | |
| list< string > | supported_inline_prefixes |
| A list of inline prefixes that are supported by this url object. More... | |
Additional Inherited Members | |
| Public Types inherited from H3D::Node | |
| typedef std::map< Node *, Node * > | DeepCopyMap |
| A map type used during a deep copy clone() to map from original nodes to cloned nodes. | |
| Public Types inherited from H3D::X3DUrlObject | |
| enum | LoadStatus { INIT , LOADED , LOADING , FAILED } |
| The load status of the given url. More... | |
| Static Public Member Functions inherited from H3D::Node | |
| static unsigned int | nrNodesAlive () |
| Returns the nr of nodes currently alive, i.e. nodes created but not destructed. | |
| static int | nrNodesCreated () |
| Returns the number of nodes created in total since the start of the program. | |
| Static Protected Member Functions inherited from H3D::Node | |
| static Node * | getClonedInstance (Node *original, bool deepCopy, DeepCopyMap &deepCopyMap) |
| A helper function for nodes that implement clone() More... | |
Detailed Description
DeviceLog records haptic device data to a binary data file.
It is essentially a ForceEffect that always calculates a zero force and logs data for the haptics device.
Warning. If any of the fields of this node changes ( with the exception of metadata ) a new log will be created and possibly old data in the file(s) pointed to in the url field will be overwritten.
For information on how to read the log created by this node see comments for the logBinary field.
Examples:
- DeviceLog.x3d ( Source )
Constructor & Destructor Documentation
◆ ~DeviceLog()
|
virtual |
Destructor.
Note: It is guaranteed that the logging file will be flushed and closed once the DeviceLog node is destroyed.
Member Function Documentation
◆ traverseSG()
|
virtual |
Adds the effect to be rendered in the haptics loop.
- Parameters
-
ti The TraverseInfo object containing information about the traversal.
Reimplemented from H3D::Node.
References H3D::TraverseInfo::addForceEffect(), createLogForceEffect(), H3D::H3DForceEffect::deviceIndex, H3D::TraverseInfo::getHapticsDevices(), H3D::TraverseInfo::hapticsEnabled(), log_force_effect, and H3DUtil::AutoRefVector< class >::size().
Member Data Documentation
◆ close
| H3DUniquePtr< OnClose > H3D::DeviceLog::close |
If set to true the log file is closed immediately.
Access type: inputOnly
◆ frequency
| H3DUniquePtr< SFInt32 > H3D::DeviceLog::frequency |
◆ logBinary
| H3DUniquePtr< SFBool > H3D::DeviceLog::logBinary |
If true the logging will be done to a binary file.
If false The logging will be done to a ASCII-text file. When logging to a text file the first line will contain information about what will be logged encoded as strings which is one of the strings which are valid for the logData field. The ALL string will never show up. When logging to a binary file the file format will be the following. The first bytes should be read as characters into a string. When two consecutive '\0'-characters are found the section with different strings are over. These strings correspond to the first line in a text file. When the first strings are read the data that follows will be in the order listed by the strings. In an ascii-file each line will contain one log entry for each of the strings, each number is separated by space. In the binary file the numbers will follow eachother without any separating bytes. The encoding will be as follows: TIME - double TIMESTAMP - double TRACKER_POSITION - double double double TRACKER_ORIENTATION - double double double double TRACKER_VELOCITY - double double double DEVICE_POSITION - double double double DEVICE_ORIENTATION - double double double double DEVICE_VELOCITY - double double double BUTTONS - int FORCE - double double double TORQUE - double double double
The data type of the containing value in the field corresponding to the value decides how to interpret the value when reading from file later. For example, TRACKER_POSITION could be put in an Vec3f type. For an example on how to read from a binary log file see HAPI::DeviceLog.
Access type: initializeOnly
Default value: false
Referenced by DeviceLog().
◆ logData
| H3DUniquePtr< MFString > H3D::DeviceLog::logData |
Specifies what to log.
The allowed values correspond to the following. ALL - All possible information will be stored. TIME - The time of logging. The first log entry counts as time 0. TRACKER_POSITION - The trackerPosition field of H3DHapticsDevice. TRACKER_ORIENTATION - The trackerOrientation field of H3DHapticsDevice. TRACKER_VELOCITY - The trackerVelocity field of H3DHapticsDevice. DEVICE_POSITION - The devicePosition field of H3DHapticsDevice. DEVICE_ORIENTATION - The deviceOrientation field of H3DHapticsDevice. DEVICE_VELOCITY - The deviceVelocity field of H3DHapticsDevice. BUTTONS - The buttons field of H3DHapticsDevice. FORCE - The force field of H3DHapticsDevice. TORQUE - The torque field of H3DHapticsDevice.
Access type: initializeOnly
Default value: "ALL"
Allowed values: "ALL", "TIME", "TRACKER_POSITION", "TRACKER_ORIENTATION", "TRACKER_VELOCITY" "DEVICE_POSITION", "DEVICE_ORIENTATION" "DEVICE_VELOCITY", "BUTTONS" "FORCE", "TORQUE","TIMESTAMP"
Referenced by DeviceLog(), and getLogTypes().
