The LoadSensor monitors the progress and success of downloading URL elements over a network. More...
#include <H3D/LoadSensor.h>
Public Member Functions | |
| LoadSensor (Inst< SFBool > _enabled=0, Inst< SFNode > _metadata=0, Inst< SFBool > _isActive=0, Inst< SFTime > _timeOut=0, Inst< MFUrlObject > _watchList=0, Inst< SFBool > _isLoaded=0, Inst< SFTime > _loadTime=0, Inst< SFFloat > _progress=0) | |
| Constructor. | |
| virtual void | traverseSG (TraverseInfo &ti) |
| traverseSG is called once per scenegraph loop on the scene in order to traverse the scenegraph. More... | |
 Public Member Functions inherited from H3D::X3DNetworkSensorNode | |
| X3DNetworkSensorNode (Inst< SFBool > _enabled=0, Inst< SFNode > _metadata=0, Inst< SFBool > _isActive=0) | |
| Constructor. | |
| Public Member Functions inherited from H3D::X3DSensorNode | |
| X3DSensorNode (Inst< SFBool > _enabled=0, Inst< SFNode > _metadata=0, Inst< SFBool > _isActive=0) | |
| Constructor. | |
| Public Member Functions inherited from H3D::X3DChildNode | |
| X3DChildNode (Inst< SFNode > _metadata=0) | |
| Constructor. | |
| Public Member Functions inherited from H3D::X3DNode | |
| X3DNode (Inst< SFNode > _metadata=0) | |
| Constructor. | |
| X3DMetadataObject * | getMetadataByName (const string &_name) |
| Given a name, the first X3DMetadataObject in the metadata field that matches that name is returned. More... | |
| Public Member Functions inherited from H3D::Node | |
| Node () | |
| Constructor. | |
| virtual Node * | clone (bool deepCopy=true, DeepCopyMap *deepCopyMap=NULL) |
| Returns a new instance of this node type with the same state as this one. More... | |
| virtual | ~Node () |
| Destructor. | |
| X3DPrototypeInstance * | getProtoInstanceParent () |
| If this node is the root node in the proto body of a X3DPrototypeInstance then this will return that node. More... | |
| void | setProtoInstanceParent (X3DPrototypeInstance *p) |
| Set the X3DPrototypeInstance this node is the the root node if applicaple. | |
| virtual void | render () |
| the render() function is used for the depth-first rendering traversal of the scene-graph. More... | |
| virtual bool | lineIntersect (const Vec3f &from, const Vec3f &to, LineIntersectResult &result) |
| Detect intersection between a line segment and the Node. More... | |
| virtual void | closestPoint (const Vec3f &p, NodeIntersectResult &result) |
| Find closest point on Node to p. More... | |
| virtual bool | movingSphereIntersect (H3DFloat radius, const Vec3f &from, const Vec3f &to, NodeIntersectResult &result) |
| Detect collision between a moving sphere and the Node. More... | |
| virtual string | defaultXMLContainerField () |
| Returns the default xml containerField attribute value. More... | |
| virtual Field * | getField (const string &_name) const |
| return a pointer to the field specified by name within this instance | |
| int | addDestructCallback (void(*func)(Node *, void *), void *args) |
| Add a callback function to be run on destruction of node. More... | |
| int | removeDestructCallback (void(*func)(Node *, void *), void *args) |
| Add a callback function to be run on destruction of node. More... | |
Public Attributes | |
| H3DUniquePtr< MFUrlObject > | watchList |
| The watchList field contains one or more URL objects to monitor. More... | |
| H3DUniquePtr< SFTime > | timeOut |
| The timeOut field specifies the maximum time for which the LoadSensor will monitor loading, starting from when the sensor becomes active. More... | |
| H3DUniquePtr< SFBool > | isLoaded |
| The isLoaded field generates events when loading of the LoadSensor's watchList has completed. More... | |
| H3DUniquePtr< SFTime > | loadTime |
| The loadTime event is generated when loading of the LoadSensor's watchList has successfully completed. More... | |
| H3DUniquePtr< SFFloat > | progress |
| The progress field generates events as loading progresses. More... | |
| Public Attributes inherited from H3D::X3DSensorNode | |
| H3DUniquePtr< SFBool > | enabled |
| If enabled is true the sensor node is enabled otherwise it is disabled and will not generate any output. More... | |
| H3DUniquePtr< SFBool > | isActive |
| A sensor is active when some special conditions are fulfilled and it will then generate extra output. More... | |
| Public Attributes inherited from H3D::X3DNode | |
| H3DUniquePtr< SFNode > | metadata |
| Meta data about the node. More... | |
Additional Inherited Members | |
| Public Types inherited from H3D::Node | |
| typedef std::map< Node *, Node * > | DeepCopyMap |
| A map type used during a deep copy clone() to map from original nodes to cloned nodes. | |
| Static Public Member Functions inherited from H3D::Node | |
| static unsigned int | nrNodesAlive () |
| Returns the nr of nodes currently alive, i.e. nodes created but not destructed. | |
| static int | nrNodesCreated () |
| Returns the number of nodes created in total since the start of the program. | |
| Static Public Attributes inherited from H3D::X3DSensorNode | |
| static H3DNodeDatabase | database |
| The H3DNodeDatabase for this node. | |
| Static Public Attributes inherited from H3D::X3DNode | |
| static H3DNodeDatabase | database |
| The H3DNodeDatabase for this node. | |
| Protected Member Functions inherited from H3D::Node | |
| void | cloneFieldValue (Field &_from, Field &_to, bool deepCopy, DeepCopyMap &deepCopyMap) |
| A helper function for the clone() method. More... | |
| Static Protected Member Functions inherited from H3D::Node | |
| static Node * | getClonedInstance (Node *original, bool deepCopy, DeepCopyMap &deepCopyMap) |
| A helper function for nodes that implement clone() More... | |
Detailed Description
The LoadSensor monitors the progress and success of downloading URL elements over a network.
Only nodes that contain a valid URL field (i.e., descendants of X3DUrlObject), may be specified in the watchList field. Multiple nodes may be watched with a single LoadSensor.
The timeOut field specifies the maximum time for which the LoadSensor will monitor loading, starting from when the sensor becomes active. A value of 0 for the timeOut field indicates an indefinite time out period; i.e., the LoadSensor will wait until loading has completed either with success or failure.
The watchList field contains one or more URL objects to monitor. Only nodes that contain a valid URL field (i.e., descendants of X3DUrlObject), may be specified as elements of watchList. If multiple values are specified for this field, output events are generated only when all of the children have loaded or at least one has failed. If individual load status information is desired for different nodes, multiple LoadSensor nodes may be used, each with a single watchList element.
The isActive field generates events when loading of the LoadSensor's watchList elements begins and ends. An isActive TRUE event is generated when the first element begins loading. An isActive FALSE event is generated when loading has completed, either with a successful load of all objects or a failed load of one of the objects, or when the timeout period is reached as specified in the timeout field.
The isLoaded field generates events when loading of the LoadSensor's watchList has completed. An isLoaded TRUE event is generated when all of the elements have been loaded. An isLoaded FALSE event is generated when one or more of the elements has failed to load, or when the timeout period is reached as specified in the timeout field. If all elements in the watchlist are already loaded by the time the LoadSensor is processed, the LoadSensor shall generate an isLoaded event with value TRUE and a progress event with value 1 at the next event cascade.
The loadTime event is generated when loading of the LoadSensor's watchList has successfully completed. If loading fails or the timeout period is reached, a loadTime event is not generated.
The progress field generates events as loading progresses. The value of progress is a floating-point number between 0 and 1 inclusive. A value of 1 indicates complete loading of all watchList elements. The exact meaning of all other values (i.e., whether these indicate a percentage of total bytes, a percentage of total number of files, or some other measurement) and the frequency with which progress events are generated are browser-dependent. Regardless, the browser shall in all cases guarantee that a progress value of 1 is generated upon successful load of all URL objects.
The following example defines a LoadSensor that monitors the progress of loading two different ImageTexture nodes:
Shape { appearance Appearance { material Material { texture DEF TEX1 ImageTexture { url "Amypic.png" } } } geometry Sphere {} } Shape { appearance Appearance { material Material { texture DEF TEX2 ImageTexture { url "Bmypic.png" } } } geometry Sphere {} } DEF LS LoadSensor { watchList [ USE TEX1, USE TEX2 ] } ROUTE LS.loadTime TO MYSCRIPT.loadTime
-
Success of all children:
- isLoaded = true
- loadTime = now
- progress = 1
- isActive = false
-
Timeout of any children, failure of any children, or no network present:
- isLoaded = false
- isActive = false
For watchList elements that allow dynamic reloading of their contents, any reload of that element (EXAMPLE changing the url field of an ImageTexture or setting the load field of an Inline), resets the LoadSensor so that it monitors those elements based on the new values and resets its timeout period if one was specified.
For streamed media types, the first frame of data available means successful load of the URL object (i.e., the browser can render one frame of a movie or start playing an audio file).
Examples:
- LoadSensor.x3d ( Source )
Member Function Documentation
◆ traverseSG()
|
virtual |
traverseSG is called once per scenegraph loop on the scene in order to traverse the scenegraph.
During this traversal things can be updated in the node and HapticObject instances to be rendered should be added to the TraverseInfo object.
- Parameters
-
ti The TraverseInfo object containing information about the traversal.
Reimplemented from H3D::Node.
References H3D::X3DSensorNode::enabled, H3D::X3DUrlObject::FAILED, H3D::X3DSensorNode::isActive, isLoaded, H3D::X3DUrlObject::LOADED, H3D::X3DUrlObject::LOADING, H3D::X3DUrlObject::loadProgress(), H3D::X3DUrlObject::loadStatus(), loadTime, progress, timeOut, H3D::Node::traverseSG(), and watchList.
Member Data Documentation
◆ isLoaded
| H3DUniquePtr< SFBool > H3D::LoadSensor::isLoaded |
The isLoaded field generates events when loading of the LoadSensor's watchList has completed.
An isLoaded TRUE event is generated when all of the elements have been loaded. An isLoaded FALSE event is generated when one or more of the elements has failed to load, or when the timeout period is reached as specified in the timeout field. If all elements in the watchlist are already loaded by the time the LoadSensor is processed, the LoadSensor shall generate an isLoaded event with value TRUE and a progress event with value 1 at the next event cascade.
Access type: outputOnly
Referenced by LoadSensor(), and traverseSG().
◆ loadTime
| H3DUniquePtr< SFTime > H3D::LoadSensor::loadTime |
The loadTime event is generated when loading of the LoadSensor's watchList has successfully completed.
If loading fails or the timeout period is reached, a loadTime event is not generated.
Access type: outputOnly
Referenced by LoadSensor(), and traverseSG().
◆ progress
| H3DUniquePtr< SFFloat > H3D::LoadSensor::progress |
The progress field generates events as loading progresses.
The value of progress is a floating-point number between 0 and 1 inclusive. A value of 1 indicates complete loading of all watchList elements.
Access type: outputOnly
Referenced by LoadSensor(), and traverseSG().
◆ timeOut
| H3DUniquePtr< SFTime > H3D::LoadSensor::timeOut |
The timeOut field specifies the maximum time for which the LoadSensor will monitor loading, starting from when the sensor becomes active.
A value of 0 for the timeOut field indicates an indefinite time out period; i.e., the LoadSensor will wait until loading has completed either with success or failure.
Access type: inputOutput Default value: 0
Referenced by LoadSensor(), and traverseSG().
◆ watchList
| H3DUniquePtr< MFUrlObject > H3D::LoadSensor::watchList |
The watchList field contains one or more URL objects to monitor.
Only nodes that contain a valid URL field (i.e., descendants of X3DUrlObject), may be specified as elements of watchList. If multiple values are specified for this field, output events are generated only when all of the children have loaded or at least one has failed.
Access type: inputOutput
Referenced by traverseSG().
