Specifies parameters to use for when rendering an object with OpenHaptics. More...
#include <H3D/OpenHapticsOptions.h>
Public Member Functions | |
| OpenHapticsOptions (Inst< SFNode > _metadata=0, Inst< SFString > _GLShape=0, Inst< SFBool > _useAdaptiveViewport=0, Inst< SFBool > _useHapticCameraView=0, Inst< SFBool > _forceFullGeometryRender=0) | |
| Constructor. | |
 Public Member Functions inherited from H3D::H3DOptionNode | |
| H3DOptionNode (Inst< SFNode > _metadata=0) | |
| Constructor. | |
| virtual string | defaultXMLContainerField () |
| Returns the default xml containerField attribute value. More... | |
| Public Member Functions inherited from H3D::X3DNode | |
| X3DNode (Inst< SFNode > _metadata=0) | |
| Constructor. | |
| X3DMetadataObject * | getMetadataByName (const string &_name) |
| Given a name, the first X3DMetadataObject in the metadata field that matches that name is returned. More... | |
| Public Member Functions inherited from H3D::Node | |
| Node () | |
| Constructor. | |
| virtual Node * | clone (bool deepCopy=true, DeepCopyMap *deepCopyMap=NULL) |
| Returns a new instance of this node type with the same state as this one. More... | |
| virtual | ~Node () |
| Destructor. | |
| X3DPrototypeInstance * | getProtoInstanceParent () |
| If this node is the root node in the proto body of a X3DPrototypeInstance then this will return that node. More... | |
| void | setProtoInstanceParent (X3DPrototypeInstance *p) |
| Set the X3DPrototypeInstance this node is the the root node if applicaple. | |
| virtual void | render () |
| the render() function is used for the depth-first rendering traversal of the scene-graph. More... | |
| virtual void | traverseSG (TraverseInfo &ti) |
| traverseSG is called once per scenegraph loop on the scene in order to traverse the scenegraph. More... | |
| virtual bool | lineIntersect (const Vec3f &from, const Vec3f &to, LineIntersectResult &result) |
| Detect intersection between a line segment and the Node. More... | |
| virtual void | closestPoint (const Vec3f &p, NodeIntersectResult &result) |
| Find closest point on Node to p. More... | |
| virtual bool | movingSphereIntersect (H3DFloat radius, const Vec3f &from, const Vec3f &to, NodeIntersectResult &result) |
| Detect collision between a moving sphere and the Node. More... | |
| virtual Field * | getField (const string &_name) const |
| return a pointer to the field specified by name within this instance | |
| int | addDestructCallback (void(*func)(Node *, void *), void *args) |
| Add a callback function to be run on destruction of node. More... | |
| int | removeDestructCallback (void(*func)(Node *, void *), void *args) |
| Add a callback function to be run on destruction of node. More... | |
Public Attributes | |
| H3DUniquePtr< SFString > | GLShape |
| Specifies the OpenHaptics shape type to use when rendering shapes using OpenGL. More... | |
| H3DUniquePtr< SFBool > | useAdaptiveViewport |
| The default setting for use of adaptive viewport. More... | |
| H3DUniquePtr< SFBool > | useHapticCameraView |
| The default setting for use of haptic camera view. More... | |
| H3DUniquePtr< SFBool > | forceFullGeometryRender |
| If set to true all X3DGeometryNodes will be rendered fully using OpenHaptics. More... | |
| Public Attributes inherited from H3D::H3DOptionNode | |
| H3DUniquePtr< Field > | updateOption |
| Field to collect update event from every option parameters, all inherited Option Node should route its option parameter fields to it. | |
| Public Attributes inherited from H3D::X3DNode | |
| H3DUniquePtr< SFNode > | metadata |
| Meta data about the node. More... | |
Static Public Attributes | |
| static H3DNodeDatabase | database |
| The H3DNodeDatabase for this node. | |
| Static Public Attributes inherited from H3D::X3DNode | |
| static H3DNodeDatabase | database |
| The H3DNodeDatabase for this node. | |
Additional Inherited Members | |
| Public Types inherited from H3D::Node | |
| typedef std::map< Node *, Node * > | DeepCopyMap |
| A map type used during a deep copy clone() to map from original nodes to cloned nodes. | |
| Static Public Member Functions inherited from H3D::Node | |
| static unsigned int | nrNodesAlive () |
| Returns the nr of nodes currently alive, i.e. nodes created but not destructed. | |
| static int | nrNodesCreated () |
| Returns the number of nodes created in total since the start of the program. | |
| Protected Member Functions inherited from H3D::Node | |
| void | cloneFieldValue (Field &_from, Field &_to, bool deepCopy, DeepCopyMap &deepCopyMap) |
| A helper function for the clone() method. More... | |
| Static Protected Member Functions inherited from H3D::Node | |
| static Node * | getClonedInstance (Node *original, bool deepCopy, DeepCopyMap &deepCopyMap) |
| A helper function for nodes that implement clone() More... | |
Detailed Description
Specifies parameters to use for when rendering an object with OpenHaptics.
Examples:
Member Data Documentation
◆ forceFullGeometryRender
| H3DUniquePtr< SFBool > H3D::OpenHapticsOptions::forceFullGeometryRender |
If set to true all X3DGeometryNodes will be rendered fully using OpenHaptics.
If false, only the triangles rendered depending on the options in HapticsOptions will be rendered. If you want to make sure that all triangles are sent to OpenHaptics to be rendered you should set this to true. Observe however that if you set this to true, you have to use the OpenHapticsRenderer or you will get no haptics at all on the geometry.
Default value: false
Access type: inputOutput
Referenced by OpenHapticsOptions().
◆ GLShape
| H3DUniquePtr< SFString > H3D::OpenHapticsOptions::GLShape |
Specifies the OpenHaptics shape type to use when rendering shapes using OpenGL.
If "FEEDBACK_BUFFER" feedback buffer shapes are used and if "DEPTH_BUFFER" depth buffer shapes are used. Feedback buffer shapes give more accurate haptics rendering since it uses the actual triangles that are rendered. However more complex models might slow things down considerably. Depth buffer shapes are not as dependent on the complexity of the geometry, but instead uses the depth buffer that is of the same resolution no matter how many triangles are rendered into it.
Valid values: "FEEDBACK_BUFFER" or "DEPTH_BUFFER"
Default value: "FEEDBACK_BUFFER"
Access type: inputOutput
Referenced by OpenHapticsOptions().
◆ useAdaptiveViewport
| H3DUniquePtr< SFBool > H3D::OpenHapticsOptions::useAdaptiveViewport |
The default setting for use of adaptive viewport.
When using depth buffer shapes, performance may be improved by enabling the adaptive viewport optimization. This optimization limits the region of the depth buffer that is read into memory to be used for haptic rendering to the area near the current proxy position. The performance improvement will depend on the speed at which the graphics card is able to read the depth image from the on board memory of the graphics accelerator. On many graphics accelerators, reading data from the depth buffer can be very costly.
Default value: true
Access type: inputOutput
Referenced by OpenHapticsOptions().
◆ useHapticCameraView
| H3DUniquePtr< SFBool > H3D::OpenHapticsOptions::useHapticCameraView |
The default setting for use of haptic camera view.
When the haptic camera view is enabled, HLAPI will automatically modify the viewing parameters used when rendering a depth buffer or feedback buffer shape so that only a subset of the geometry near the proxy position will be rendered. When the haptic camera view is enabled, HLAPI modifies the OpenGL view frustum so that only the shape geometry near the proxy position is rendered. For feedback buffer shapes, this can dramatically increase performance by reducing the number of geometric primitives considered for haptic rendering. The improvement will depend on the density of the geometry in the region around the proxy, since denser geometry will lead to a larger number of primitives in the haptic view frustum. For depth buffer shapes, this offers less of a performance improvement, since once the primitives have been rendered to the depth buffer, the actual haptic rendering of a depth buffer image is not dependent on the number of primitives. That said, there is some performance benefit to considering only the geometry near the proxy when generating a depth buffer image. In addition, when using haptic camera view, HLAPI generates a depth buffer image that is a subset of the full depth buffer used by the graphics window so as with adaptive viewport, less data is read back from the depth buffer. If haptic camera view is enabled, the adaptive viewport setting is ignored. In addition, for depth buffer shapes, using haptic camera view allows you to feel parts of the geometry that are not viewable from the graphics view.
Default value: true
Access type: inputOutput
Referenced by OpenHapticsOptions().
